Baumer AL-H-2-4BM-(0/25) KG/CM² Stainless Steel Pressure Gauge

Nominal size

150 MM

Case material

Stainless steel AISI 304

Bezel ring material

Stainless steel AISI 304

Window material

Plexi glass
(Optional) Shatterproof/safety glass / Toughened glass

Gasket & filling plug

Neoprene
Viton (Optional)

Protection rating (IS/IEC 60529)

IP 65

Dial

White, Aluminium

Pointer

Black, Aluminium

Movement Material

Stainless steel AISI 304 SS
Stainless steel AISI 316 SS (Optional)

Safety according to EN 837-1

S1, Pressure gauge with blow-out device

Ambient temperature

-25°C … +65°C

Media temperature

Max +300°C (not filled)
Max +100°C (Glycerine filled)
Max +200°C (Silicone oil filled)

Process connection material

Stainless steel AISI 316L
Monel (Optional)

Bourdon tube

Stainless steel AISI 316L
Monel (Optional)

Accuracy according to EN 837-1

Class 1

Min. measuring range

0 … 0.6 bar

Max. measuring range

0 … 1600 bar

Type of pressure

Gauge
Compound
Vacuum

Over pressure limit

≤ 100 bar : 125 % of Max. scale value
> 100 to ≤ 600 bar : 115 % of Max. scale value
> 600 to ≤ 1600 bar : 110 % of Max. scale value

Thermal drift (reference: +20 °C)

± 0.4 % FS/10K
