Magnetic Flowmeter 9500A

Foxboro Magnetic Flowmeter

$3776.00$2345.00

Range of Product	Flow
Product or Component Type	Magnetic flowmeter transmitter
Device Application	To measure the flow of pressure for liquid, gas, steam
Market Segment	Food and beverage Pharmaceutical Cosmetics Power
Product Specific Application	Water abstraction Drinking water dstribution network Irrigation Process water Cooling water Wastewater Purification Desalination Mining minerals and metals
Device composition	Tube diameter	0.10…5.9 in (2.5…150 mm) 0.1…6 in (2.5…152.4 mm)
	Communication Port Protocol	Hart protocol tolerance FOUNDATION fieldbus Modbus
	Measurement accuracy	+/- 0.3 % of reading with IMT31A +/- 0.2 % of reading with IMT33A
	Drift of the sensitivity	+/- 0.01 %
	Housing material	Stainless steel
	Name of test	Vibration Shocks
	Mounting support	Flange
	Mounting location	Wall mounting (with IMT30A) Wall mounting (with IMT31A) Field mounting (with IMT33A)

Ambient air temperature for operation	23…176 °F (-5…80 °C) with hard rubber liner 23…194 °F (-5…90 °C) with polypropylene liner 23…176 °F (-5…80 °C) with polyolefin liner
Product Certifications	CE ATEX FM CSA
Standards	IEC 60529
