Magnetic Flowmeter 9600A

Foxboro Magnetic Flowmeter

$3550.00$2345.00

Range of Product	Flow
Product or Component Type	Magnetic flowmeter transmitter
Device Application	To measure the flow of pressure for liquid, gas, steam
Market Segment	Pharmaceutical Power
Product Specific Application	To measure flow with beverage containing solid media Clean-in-place Mixing Batching Dosing
Device composition	liner PFA (perfluoroalkoxy) electrode hastelloy electrode stainless steel electrode titanium electrode platinum electrode tantalum

Tube diameter	0.10…5.9 in (2.5…150 mm) 0.1…6 in (2.5…152.4 mm)
Communication Port Protocol	Hart protocol tolerance FOUNDATION fieldbus Modbus
Measurement accuracy	+/- 0.3 % of reading with IMT31A +/- 0.2 % of reading with IMT33A
Drift of the sensitivity	+/- 0.01 %
Housing material	Stainless steel
Name of test	Vibration Shocks
Mounting support	Flange
Mounting location	Dierctly connect to the signal converter (with IMT30A) Dierctly connect to the signal converter (with IMT31A) Dierctly connect to the signal converter (with IMT33A) Wall mounting (with IMT30A) Wall mounting (with IMT31A) Field mounting (with IMT33A)

Ambient air temperature for operation	-40…248 °F (-40…120 °C) compact with IMT30A -40…248 °F (-40…120 °C) compact with IMT31A -40…284 °F (-40…140 °C) compact with IMT33A
Product Certifications	CE ATEX FM CSA
Standards	IEC 60529
